KIDS | KIDS

ACE24

ACE24

ACEの24インチホイールバージョン。パドルシフト仕様なので子供の小さな手でも容易にシフトチェンジが可能。およそ130cmぐらいの身長から乗車可能。

SPECIFICATIONS

Sizes:
13.5”
Color(s):
Navy , Red
Main frame:
A2-SL alloy, forged-road dropout w/ replaceable derailleur hanger
Fork:
Fuji 1 1/8" custom-aero steel
Crankset:
Alloy, 48/40T, 152mm
Bottom bracket:
Semi-cartridge bearing
Pedals:
Fuji Road
Front derailleur:
Shimano A050, 31.8mm clamp
Rear derailleur:
Shimano Tourney, 7-speed
Shifters:
Shimano A050, handlebar mount, 7-speed
Cassette:
Shimano Tourney, freewheel, Mega Range 14-28T, 7-speed
Chain:
KMC HV500, 7-speed
Wheelset:
Vera Corsa DPM27, double wall, 20/24h, Formula road hubs
Tires:
Vera Invictus, 24×1", 30tpi
Brake set:
Alloy dual pivot
Brake levers:
Fuji aero alloy
Headset:
FSA 1 1/8"
Handlebar:
Fuji 6061 alloy Road, 26mm
Stem:
Fuji Road,75mm
Tape/grip:
Fuji foam wrap
Saddle:
Oval Concepts 300 Youth
Seat post:
Fuji alloy, 27.2mm
Weight:
9.3kg

GEOMETORY

SIZE24”
SEAT TUBE CENTER TO TOP 345
TOP TUBE EFFECTIVE477
HEAD TUBE LENGTH110
SEAT TUBE ANGLE74.5
HEAD TUBE ANGLE 71
CHAINSTAY LENGTH365
WHEELBASE909
F.OFFSET45
BOTTOM BRACKET DROP35
REACH-
STANDOVER 623
STEM 75
HANDLEBAR WIDTH360
CRANK152
