• SUPREME 1.0
  • SSTのDNAを受け継ぐフルカーボンロードバイク。流麗で有機的なフレームデザインは、強化リブを施すことにより駆動系周りのフレーム剛性を高めているだけでなく、高弾性が特徴のD6カーボンの恩恵により様々なシーンで高い順応性を示し、ロングライドからレースまで幅広く対応。
    スモールサイズが充実したジオメトリーで本格派の女性ライダーもサポート。
  • Photo
  • Color(S)
  • Carbon/Green/White
  • Price
  • (完成車)¥294,000(本体価格¥280,000)
  • Size
  • 44cm, 47cm, 50cm, 53cm
  • Main frame
  • D-6 high modulus carbon w/ RIB Tech, integrated head tube w/ 1 1/2” lower, aero seat tube, internal cable routing,oversized PIIS BB-86 shell, double water bottle mounts
  • Fork
  • FC-440 carbon monocoque w/ RIB Tech, tapered carbon steerer & carbon dropout
  • Crankset
  • Oval 700 forged alloy, 34/50T
  • Bottom bracket
  • Press-Fit BB86 sealed bearing
  • Front derailleur
  • Shimano Ultegra, braze-on mount
  • Rear derailleur
  • Shimano Ultegra, 10-speed
  • Shifters
  • Shimano Ultegra STI shifter/brake combo, 20-speed Flight Deck compatible
  • Cassette
  • Shimano Ultegra, 11-28T 10-speed
  • Wheelset
  • Oval 330 aero alloy clincher, 30mm rims - 700c, DT Champion spokes, 20/24H, precision ground hubs
  • Tires
  • Hutchinson Equinox, 700x23c, folding
  • Brake set
  • Oval 500 forged alloy dual pivot w/ cartridge pads
  • Headset
  • Oval 1 1/8”U - 1 1/2”L integrated w/ alloy top cover
  • Handlebar
  • Oval 300S double-butted 6061 alloy, 31.8mm
  • Stem
  • Oval 300 3D forged 6061 alloy, 31.8mm, +/-6 degree
  • Saddle
  • Selle Italia X-1 Lady Flow w/ FeC alloy rails
  • Seat post
  • Oval 300 alloy 2-bolt, 31.6mm

GEOMETRY

SIZE 44cm 47cm 50cm 53cm
SEAT TUBE-CENTER TO TOP 440 470 500 530
EFFECTIVE TOP TUBE LENGTH 500 510 520 535
FORK OFFSET 50 50 50 50
HEAD TUBE ANGLE 70.5 70.5 70.5 70.5
SEAT TUBE ANGLE 75 75 75 75
CHAIN STAY 405 405 405 405
WHEELBASE 969.2 971.25 973.4 979.4
HEAD TUBE LENGTH 105 115 125 145
BOTTOM BRACKET HEIGHT 261 261 264 264
BOTTOM BRACKET DROP 7.3 7.3 7 7
STAND OVER HEIGHT 713.24 733.88 751.52 775.48
CRANK LENGTH 165 166 167 168
STEM LENGTH 90 90 100 110
HANDLEBAR WIDTH 380 380 400 400
